Fast Patrol Boat
  • Fast Patrol BoatFast Patrol Boat

Fast Patrol Boat

Rib 760 Fast Patrol Boat Aluminum Hypalon Inflatable Boat With Outboard Motor, Seastar aluminum rib boats are made of aluminum hull with inflatable hypalon tube. Some rib boat have get CE certification. Rescue boat type have more seats type for government rescue usage, also suitable for some tourism projects of non-governmental project.

Send Inquiry

Product Description

Rib 760 Fast Patrol Boat from Qingdao Seastar Sport Equipment Co.,Ltd, which is one professional rigid inflatable boat and aluminum rib boats manufacturer, also include some small aluminum boats.


Product Parameter

Botal length:

760cm

Total width:

288cm

Tube diameter:

56cm

Net weight:

about 800kgs

Max person:

13 persons

Max engine power:

250HP/186.42KW

Packing size:

750 x 200 x110 cm

Max payLoad:

1960kgs

Design category:

C

Air chamber number:

7

Packing in a container

2 sets/40 feet container

Loading port

Qingdao port,China


Standard Accessories for ALU RIB760

oars

2

Foot pump

1

Repair kit

1

front and back cabin with cushion

1

center console include windscreen,oil gauge and 4 point switch

1

seat box

1

Alu steel roll bar with 3 navigation lights

1

300L built in fuel tank

1

bilge pump with switch

1

EVA floor

1

T-top sunroof

1


Optional Accessories:(need client choice)

life jacket

13

100A battery and battery box

1

electric pump with battery

1

7.5kgs stainless steel anchor

hydraulic steering system with
steering wheel and cables

1

Boat cover

1

VHF radio

1

YAMAHA F200BETX(4stroke,
200HP) engine with vertical control box

1

Alarm lamp

1

Searchlight(Hernia white light)

1

Radar (China brand, S1000)

1

GPS(Chart of Cote d 'Ivoire,
GPS9000, Eight-inch display)

1

Testing boat in the river

1


Manufacturing Advantage

1. All of our aluminum rib boat are made of Marine-grade aluminum plate.


2. Aluminum Rib 760 Fast Patrol Boat Welding Specification :

1) TIG and MIG are to be adopted for this ship .

2) The ultrasonic inspection to be carried out for the cross joint of seam and other important place.

3) From 5083-H116 material to welding wires to welding use gas & experienced qualified welders.


3. Aluminum Patrol Boat Core Features Of Our safe Design

1) The Whole hull structure Manual bilge pump system.

2) The underfloor fuel tank with cutoff valves and fuel inspection hose with heavy duty fuel hoses.

3) Balance testing , Flotation and deck water-Tight and flotation testing make sure 100% safe .


Design Features of hull for DL rib 760

Beautiful Deep V double aluminum hull

Super light, faster speed, steady driving

Recyclable, more environmental friendly

Non-skid flooring for the comfort and safety of passengers

Automatic electric bilge pump

300L built in fuel tank


  • Production Process:

  • CE certification Wall:


Boat Color Options:


  • Rib Boat Optional Parts Choice:

  • Packing & Transport:


FAQ

Q1: Why choose us?

A1: High performance and high quality boats with 20 years experience in designing and manufacturing.


Q2:What gives you an unfair advantage?

A2: Professional design team with professional manufacturing, strict quality inspection and high quality service.


Q3: How about the warranty?

A3:  We use high quality German Valmex PVC/ French ORCA fabric or Taiwan Hypalon tube material, which are durable with 3 to 5 years warranty.


Fast patrol boat rib boat 760 more questions and inquiry, please contact us by email or directly send us messages by whatsapp number +8615666791560.
